Semi-Hermetic Screw Cast Iron Chiller for -40℃ Cold Storage

Semi-hermetic & Screw Compressor Unit Air Cooled Chiller -5~-40°

Share to:

· FOB Price: Negotiable
· Min.Order Quantity: 1 0Piece
· Producing Capacity: 5000 Pieces per Month
· Port: Ningbo
· Payment Terms: L/C,T/T
· Origin plant: Zhejiang,China
· Compressor Body Material: Iron
· Application: Refrigeration
· Refrigerant: R22, R134A, R404A，R507C, R407C
· Power(V/Ф/Hz ): 380-420/3/50, 440-480/3/60
· Certification: CE, CCC, ISO9001,etc
· Cross reference: BITZER, COPELAND, INVOTECH

Availability:

Quantity:



Inquire Add to Basket

Cast Iron Chiller for -40℃ Cold Storage Semi-Hermetic Chiller Screw Cast Iron Chiller Screw Chiller Screw Cast Iron Chiller for -40℃ Cold Storage

Product Description

Technical Specifications

Cooling Performance

FAQ

Scene-Specific Solutions for Water-Scarce & Outdoor Environments

In regions with limited water resources or outdoor low-temperature applications, our Air Cooled Chiller (-5~-40℃) eliminates the need for water supply, solving key pain points:

Remote Area Cold Chain: Powers mobile cold trucks and temporary storage in deserts or mountainous areas, maintaining -15~-40℃ for frozen foods and vaccines.

Outdoor Industrial Equipment: Cools low-temperature testing chambers (e.g., for automotive parts) and outdoor refrigeration units, withstanding ambient temperatures as low as -10℃.

Laboratory Deep-Cold Experiments: Supports material science labs requiring -20~-35℃ for cryogenic testing, ensuring temperature stability with ±0.3℃ precision.

Cast Iron Chiller for -40℃ Cold Storage

Product Design & Material Advantages

Air-Cooled Efficiency & Reliability

High-Performance Condenser: FNHM/FNVT-series air-cooled condensers with large air flow (6000~36000 m³/h) ensure efficient heat dissipation even in low ambient temperatures.

Built-In Receiver: 6~45L receivers store refrigerant, stabilizing system operation and reducing frequent refilling needs—critical for remote sites.

Durable & Weather-Resistant Materials

Compressor Body: Cast iron with weatherproof paint, resisting rain, dust, and UV radiation for outdoor use; service life extends to 12 years in harsh conditions.

Fan Motors: High-torque motors (compatible with 380~480V/50~60Hz) operate smoothly at -35℃, with low friction bearings reducing maintenance frequency.

Technical Support & After-Sales Service

On-Site Installation: Engineers travel to remote locations for installation, ensuring proper alignment of the condenser with wind direction to maximize heat dissipation.

Maintenance Training: Free training for on-site staff on cleaning the condenser (to remove dust/snow) and checking refrigerant levels—critical for air-cooled unit performance.

Spare Parts Delivery: Emergency spare parts (e.g., fan blades, compressors) shipped via DHL/FedEx, with 3-day delivery to most countries.

Energy Audit: Optional annual energy audit service to optimize operating parameters (e.g., fan speed, condensing temperature) and reduce energy costs.

Model	Power	EvaporatingTemp.	EnvironmentTemp.	Condenser		Dimension (mm)			Installation Size (mm)		Connecting Pipe ( φ :mm)		Weight( kg)
Specification	Power	EvaporatingTemp.	EnvironmentTemp.	Air Flow( m³/h)	Model	A	B	C	E	F	Suction	Liquid	Weight( kg)
4YD-3.2	380~420V-3PH-50Hz	-5~-40℃	-10~-35℃	1.7	SLKD-003/B	827	330	660	500	280	22	12	138
4YD-4.2				2.6	SLKD-005/B1	827	330	660	500	280	28	12	143
4YD-5.2				2.6	SLKD-005/B1	827	330	660	500	280	28	12	146
4YD-8.2				4.9	SLKD-010/B1	1127	330	715	800	280	35	16	205
4YD-10.2				4.9	SLKD-010/B1	1127	330	715	800	280	35	16	219
4VD-15.2				7.6	SLKD-015/B1	1250	380	760	900	330	42	22	304
4VD-20.2				8.9	SLKD-020/B1	1250	380	760	900	330	54	22	317
6WD-30.2				12.2	SLKD-030/B1	1650	380	810	1100	330	54	22	378
6WD-40.2				18.3	SLKD-040/B1	1621	380	810	1100	330	54	28	402

Model	Condensing Temperature℃	Cooling Capacity Qo（W） Power Consumption Pe(kW)
		Evaporating Temperature ℃
			7.5	5	0	-5	-10	-15	-20	-25	-30	-35	-40
BFS51	30	Qo	24000	22200	18600	15400	12600	10200	8500	6700	5300	4000	3000
BFS51	40	Qo	20400	18900	15800	13100	10700	8700	7200	5700	4500	3400	2600
BFS81	30	Qo	31400	28700	24000	20000	16400	13400	10700	8500	6500	4900	3700
BFS81	40	Qo	26400	24100	20200	16800	13800	11300	9000	7100	5500	4200	3100
BFS101	30	Qo	44800	44200	35100	29000	23900	19400	15600	12300	9500	7200	5300
BFS101	40	Qo	38100	35600	29800	24600	20300	16500	13200	10500	8100	6100	4500
BFS151	30	Qo	69000	64500	54300	45200	37300	30500	25600	19600	15300	11700	8900
BFS151	40	Qo	58700	54800	46200	38400	31700	25900	21800	16700	13000	9900	7500
Based on 20℃ suction gas temperature,50Hz,without liquid subcooling.
Additional cooling or limited suction gas temperature.
Additional cooling and CIC system.

Q: The equipment shuts down suddenly during operation, showing "module protection activated". What should be done?

A: First, check the cause of motor overheating (e.g., poor heat dissipation, excessive load). Repair it after identifying the cause (e.g., clean heat dissipation holes, reduce load), then restart the equipment.

Q: After ruling out motor overheating, the equipment still shuts down due to "automatic control unit protection". What needs to be inspected?

A: Focus on checking the setting parameters of the control components, such as whether the overload threshold and temperature protection upper limit are abnormal. Adjust them to standard parameters and test.

Q: If the equipment frequently triggers protection and shuts down, what preventive measures should be taken besides troubleshooting faults?

A: Regularly inspect the operating status of modules and control units, clean dust, and fasten wiring to avoid false triggering of protection due to component aging or poor contact.
